GP4048-34

Can be made with Recycled Plastics
An Ocean in Mind Product

Description

The medium-duty BulkPak 4048 GP Series was designed for a wide variety of product sizes, shapes, and weights. These bulk containers allow more parts to be handled, stored, and shipped…with fewer containers and in fewer trips. The advanced design results in a consistent tare weight that improves inventory and shipping efficiencies. Containers collapse when empty for reduced return transportation costs and warehouse space savings. During storage and shipping, these bulk bins stack securely atop each other when full. Pallet boxes offer the strength and rugged durability demanded in today’s material handling and distribution systems. Custom protective dunnage is available for all ORBIS BulkPak containers. These plastic containers are fully recyclable at the end of their service life. (All dimensions and specifications are approximate. Performance characteristics are based on uniform static loads and may be affected by the distribution of load, handling methods, number, type of access doors, and temperatures beyond the range of 0 to 120 degrees Fahrenheit.)

  • 40 x 48 x 34 footprint
  • Structural-foam molded sidewalls and structural-channel molded base
  • High-density polyethylene
  • Container capacity: 2,000 lbs
  • All-plastic construction eliminates the risk of rust
  • Self-standing sidewall for safe and efficient assembly and collapse
  • 2 access doors on 40” side
  • Base: All-plastic picture frame bottom
  • Deck: Solid or ventilated
  • Sidewalls: Solid
  • Popular applications: Produce, caps/closures, plastic/rubber parts

Additional information

Weight 142.3 lbs
Dimensions 48 × 40 × 34.1 in
Outside Length (in.)

48

Outside Width (in.)

40

Outside Height (in.)

34.1

Inside Length (in.)

45

Inside Width (in.)

37

Prod Clearance (in.)

27.7

Collapsed Height (in.)

14.1

Container Capacity (lb.)

2000

Weight (lb.)

142.3

Maximum Loaded Stack (Static)

6 High

Maximum Loaded Stack (Dynamic)

3 High

Return Ratio

2.7:1

53 ft. Trailer Qty (Assembled)

90

53 ft. Trailer Qty (Collapsed)

240
